Poles & Footings
Spun concrete Electric Pole Moulds in four standard lengths for casting prestressed spun concrete poles used in power distribution infrastructure. Built from 12mm MS plate for the structural rigidity required for repeated high-speed spinning. Available in 8mt, 9mt, 9.1mt and 10mt lengths with corresponding shell thicknesses. Widely used by electricity distribution contractors and rural electrification project suppliers across Gujarat and Rajasthan.
Suitable For
- Electricity distribution contractors (DISCOM suppliers)
- Rural electrification project manufacturers
- Street lighting pole manufacturers
- Telecom pole manufacturers
Specifications
Available Sizes
| Size | Note |
|---|---|
| 8mt pole | Shell thickness: 105mm | Standard |
| 9mt pole | Shell thickness: 135mm | Plate: 12mm | Standard |
| 9.1mt pole | Shell thickness: 150mm | Standard |
| 10mt pole | Standard - thickness on request |
| Material | MS Iron (Mild Steel) - 12mm plate |
|---|---|
| Finish | Machine finish (no colour coating - used for spun concrete process) |
| Plate Thickness | 12mm plate |
| Custom Size | Available on request |
| Custom Size Note | Custom pole lengths and shell thicknesses available on request. Specify your BIS or utility specification. |
| Plate Thickness | 12mm |
| Mould Type | Spun concrete (centrifugal casting) |
| BIS Reference | IS 1678 / IS 2905 (consult your utility spec) |
